Applications
- Suitable for fluid medium which does not corrode 304 stainless steel
Product features
- Industrial design
- Lower (bottom) connection without external reset
- All stainless steel construction
- NEMA 4X / IP 65 Weatherproof
Specifications
Size
5” (127mm)
Accuracy
+ 1.0% full scale value (ASME B40.3)
Ranges
-100oF to 1000oF (and equivalent Celsius)
Working Range
Steady: full scale value
Short time: 110% of full scale value
Under/Over Range Protection
Temporary over or under range tolerance of 50% of scale up to 500oF. (260°C). For ranges above 500°F, maximum over range is 800°F; continous. 1000°F intermittent.
Connection
Material: 304 stainless steel
Lower mount (LM), 1/2” NPT
Stem
Material: 304 stainless steel
Diameter: 1/4” (6.35 mm)
Length: 2½” to 24” (63.5 mm to 609.6 mm)
Measuring Element
Bi-metal helix
Dial
White aluminum, dished, with black markings
Case
Material: 304 stainless steel
Hermetically sealed
Ingress Protection IP 66
Pointer
Black aluminum
Standard Scales
Single: Fahrenheit or Celsius
Dual: Fahrenheit (outer) and Celsius (inner)
Window Gasket
Neoprene
Silicone (-100oF and over 550oF)
Window
Flat instrument glass
Weight
24 oz. (5” dial)
Add 1 oz for every 2” of stem length
Dampening
Inert gel to minimize pointer oscillation
Movement
Viscous inert gel to enhance pointer operation
Warranty
Limited one year warranty as stated in WIKA’s Terms & Conditions of Sale
